开放式 AC-DC 切换电源模组提供连接器型 (connector)、底板冷却型 (baseplate-cooled) 和 PCB 安装型，功率范围从 6W 到 500W，目前是市场上功率密度最高的产品。所有产品都通过了最新的 ITE 安全或医疗安全认证。还有几款最新型号，符合 EN/IEC 60335-1，并包括 200% 峰值负载的独特功能。这种特殊的 200% 峰值负载功能适合应付装置只在开启瞬间需要大量电力的情况，客户无需选择其他规格过高的产品，更可以节省成本和降低消耗。
Open Frame AC-DC switching power supplies module offers Connector type, Baseplate-cooled type and PCB mounting type, with power ranging from 6W to 500W, they are some of highest power density products in the current market. All products are approved for latest ITE safety or Medical safety. For some of our latest models, they meet EN/IEC 60335-1, and include a unique feature of 200% peak load feature. This special 200% peak load feature fulfills the need to customer sudden needs of power for a short period of time, and can now avoid choosing other products that are over-spec, save on cost and layout space/footprint consumption.
| 系 列 |
功率 (W) |
输入范围 (V) | 输出电压 (VDC) | 多路输出 | 尺寸 (mm) |
| CFM04S 新品 | 4 | AC85-305 | 3.3, 5, 12, 15, 24 | 单路 |
39.50 x 19.40 x 18.30
带T : 49.53 x 18.00 x 17.50 |
| CFM06S 新品 | 6 | AC90-264 | 3.3, 5, 9, 12, 15, 24 |
39.50 x 19.40 x 18.30 带T : 49.53 x 18.00 x 17.50 带E : 41.10 x 21.00 x 20.00 |
|
| CFM10/15 | 10-15 | AC85-264 | 3.3, 5, 9, 12, 15, 24 | 65.00 x 45.00 x 23.00 | |
| CFM12S | 12 | AC90-264 | 5, 9, 12, 15, 24 |
38.10 x 25.40 x 19.40 带T : 63.50 x 25.40 x 17.30 带E : 40.64 x 27.94 x 19.60 |
|
| CFM20 | 20 | AC85-264 | 3.3, 5, 9, 12, 15, 24 |
标准: 88.92 x 50.80 x 23.00 CFM200XS-P: 88.92 x 50.80 x 25.40 |
|
| CFM20S 新品 | 20 | AC90-264 | 5, 12, 15, 24,48 | 单路 |
60.50 x 33.02 x 23.00 带T : 63.04 x 35.60 x 23.70 带E : 76.20 x 33.02 x 21.10 |
| CFM21 医疗 | 20 | AC90-264 | 3.3, 5, 9, 12, 15, 24 |
带E : 64.20 x 44.20 x 20.40 带S : 76.20 x 40.60 x 19.50 |
|
| CFM21M 医疗 | 20 | AC90-264 | 5, 9, 12, 15, 24 |
60.50 x 40.60 x 20.40 带T :76.20 x 40.60 x 19.50 带E : 64.20 x 44.20 x 20.40 带S : 76.20 x 40.60 x 19.50 |
|
| CFM25S | 25 | AC90-264 |
5, 12, 15, 24, 36, 48 |
50.80 x 27.94 x 24.90 带T : 70.50 x 27.94 x 23.00 带E : 53.10 x 30.30 x 24.80 |
|
|
CFM36S 新品 |
36 | AC90-264 | 5, 12, 15, 24, 48 | 单路 |
76.20 x 38.10 x 27.94 带T : 76.20 x 38.10 x 25.40 带E : 78.80 x 40.70 x 28.80 |
| CFM40S | 40 | AC90-264 |
3.3, 5, 9, 12, 15, 24, 30, 36, 48 |
有外壳 : 117.00 x 62.00 x 40.00 无外壳 : 101.60 x 50.80 x 30.48 |
|
| CFM40M 医疗 | 40 | AC90-264 | 3.3, 5, 9, 12, 15, 24 | 76.20 x 50.80 x 23.10 | |
| CFM40D/T | 40 | AC90-264 | 3.3, 5, 12, 15, 24 | 双路, 三路 |
有外壳 : 101.60 x 50.80 x 27.00 无外壳 : 117.00 x 63.00 x 47.00 |
| CFM41S 新品 | 40 | AC90-264 |
5, 12, 15, 24, 36, 48 |
50.80 x 50.80 x 25.60 带T : 54.37 x 54.37 x 26.50 带E : 68.58 x 50.80 x 23.90 |
|
| CFM50S 新品 | 50 | AC90-264 | 5, 12, 15, 24, 36, 48 | 单路 | 76.20 x 50.80 x 27.10 |
| CFM60S | 60 | AC90-264 | 3.3, 5, 9, 12, 15, 24, 30, 36, 48 |
有外壳 : 101.60 x 5 0.80 x 30.48 无外壳 : 117.00 x 62.00 x 40.00 |
|
| CFM60M 医疗 | 60 | AC90-264 |
5, 12, 15, 24, 48 |
101.60 x 50.80 x 27.94 | |
| CFM60T | 60 | AC90-264 |
3.3, 5, 12, 15, 24 |
三路 | 101.60 x 50.80 x 32.00 |
| 60 | AC90-264 | 3.3, 5, 9, 12, 15, 24, 36, 48 |
50.80 x 50.80 x 34.20 带T : 768.58 x 50.80 x 32.80 带E : 754.25 x 54.25 x 35.80 |
||
| CBM70S 新品 | 70 | AC90-264 | 12, 24, 36, 48 | 61.00 x 57.90 x 17.00 | |
| CFM70S 新品 | 70 | AC90-264 | 5, 12, 15, 24, 36, 48 | 76.20 x 50.80 x 27.10 | |
| CFM80S | 80 | AC90-264 | 5, 12, 15, 24, 48 | 101.60 x 50.80 x 27.00 | |
| CFM81S 新品 | 80 | AC90-264 | 12, 15, 24, 48 | 单路 | |
| CBM100S | 100 | AC90-264 | 12, 24, 28, 36, 48 | 36.80 x 57.90 x 12.70 | |
| CBM101S 新品 | 100 | AC90-264 | 12, 24, 28, 36, 48 | 单路 | 116.80 x 61.0 x 17.0 |
| CFM100M 医疗 | 100 | AC90-264 | 5, 7.5, 9, 12, 15, 18, 24, 28, 36, 48 | 127.00 x 76.20 x 26.67 | |
| CFM130S 新品 | 130 | AC80-264 | 12, 24, 36, 48 | 50.80 x 76.20 | |
| CFM130M 医疗 新品 | 130 | AC80-264 | 12, 24, 36, 48 |
76.20 x 50.80 x 30.50 -C: 有外壳 : 91.40 x 64.0 x 34.50 -B: 无外壳 : 91.40 x 50.80 x 33.0 |
|
| CBM150S 新品 | 150 | AC90-264 | 12, 24, 28, 36, 48, 54 | 116.80 x 61.00 x 19.70 | |
| CFM150M 医疗 | 150 |
AC90-264 |
12, 24, 36, 48 | 127.00 x 76.20 x 26.67 | |
| CFM150S 新品 | 150 |
AC90-264 |
12, 24, 36, 48 |
有外壳 : 101.60 x 50.80 x 32.60 -B: 无外壳 :116.80 x 50.80 x 34.60 |
|
| CFM200M 医疗 新品 | 200 | AC90-264 | 12, 24, 36, 48 |
有外壳 : 117.00 x 63.00 x 38.00 |
|
| CFM202S 新品 | 200 | AC90-264 | 12, 24, 28, 36, 48, 56 |
有外壳 : 116.80 x 64.00 x 34.50 无外壳 : 101.60 x 50.80 x 33.30 |
|
| LFM200S 新品 | 200 | AC85-264 | 12, 15, 24, 28, 30, 36, 48, 54 |
78.60 x 57.90 x 25.40 |
|
| CFM260S 新品 | 260 | AC90-264 | 12, 24, 36, 48 |
101.60 x 50.80 x 36.60 无外壳 : 116.80 x 50.80 x 38.60 有外壳 : 116.80 x 64.00 x 40.50 |
|
| CFM300S | 300 | AC90-264 | 5, 12, 24, 36, 48 |
有外壳 : 136.00 x 87.00 x 40.40 无外壳 : 127.00 x 76.20 x 36.10 |
|
| CFM300M 医疗 新品 | 300 | AC90-264 | 12, 24, 36, 48 |
有外壳 : 127.00 x 76.20 x
28.10 无外壳 : 136.00 x 87.00 x 40.40 |
|
| LFM300M 医疗 新品 | 300 | AC85-264 | 12, 15, 24, 28, 30, 48, 54 | 104.00 x 57.90 x 25.40 | |
| LFM300S 新品 | 300 | AC85-264 | 12, 15, 24, 28, 30, 48, 54 | 单路 | 104.00 x 57.90 x 25.40 |
| CFM351M 医疗 | 350 | AC90-264 | 5, 12, 24, 48 | 165.00 x 101.60 x 38.60 | |
| CFM400S 新品 | 400 | AC80-264 | 12, 18, 24, 36, 48, 54 | 单路 |
有外壳 : 136.00 x 87.00 x 42.50 无外壳 : 127.00 x 76.20 x 39.10 |
| LFM420M 医疗 新品 | 420 | AC85-264 | 12, 15, 24, 28, 30, 36, 48, 54 | 129.40 x 83.50 x 25.40 | |
| LFM420S 新品 | 420 | AC85-264, 120-370 | 12, 15, 24, 28, 30, 36, 48, 54 | 单路 |
129.40 x 83.50 x 25.40 |
| CFM500M 医疗 新品 | 500 | AC80-264 | 5, 12, 15, 18, 36, 48 | 127.00 x 76.20 x 39.10 | |
| CFM500S 新品 | 500 | AC80-264 | 12, 18, 24, 36, 48 | 127.00 x 76.20 x 39.10 | |
|
PDF700S 新品 |
700 | AC90-264 | 12, 24, 28, 48, 56 | 116.8 x 61.00 x 12.70 | |
| PDF700S-CMFC(D/D-P)新品 | 700 | AC90-264 | 12, 24, 28, 48, 56 | 单路 |
CMFC : 240.00 x 110.00 x 40.30 CMFD(D-P) : 240.00 x 110.00 x 42.00 |
| PFC750 新品 | 750 | AC90-264 | 390 | 127.00 x 57.90 x 61.00 |
