DC-DC转换器 > 微型 SIP & DIP-24 封裝                                                                           DC-DC Converters > SIP & DIP-24

系列 功率 (W) 输入范围 (V) 输出电压 (VDC) 多路输出 尺寸 (mm)
EC6A 7.5 DC9-18, 18-36, 36-72 3.3, 5, 12, 15 双路 DIP: 31.8 x 20.3 x 10.2
SMD: 31.8 x 20.3 x 11.4
EC6AW 8 DC9-36, 18-75 3.3, 5, 12, 15 双路

DIP: 31.8 x 20.3 x 10.2

SMD: 31.8 x 20.3 x 11.4

EC6AW-110NEW 6.6-10W DC43-160 12, 15 双路

31.8 x 20.3 x 12.70

EC7A 10W DC9-18, 18-36, 36-75 3.3, 5, 12, 15 双路

DIP: 31.8 x 20.3 x 10.2

SMD: 31.8 x 20.3 x 11.4

EC6AW 15W DC9-36, 18-75 3.3, 5, 12, 15  双路

DIP: 31.8 x 20.3 x 10.2

DC-DC转换器 > 小型 1”x1”/2”x1”/2.05”x1.2” 封裝                                                DC-DC Converters > 1”x1”/2”x1"/2.05”x1.2”

系列 功率 (W) 输入范围 (V) 输出电压 (VDC) 多路输出 尺寸 (mm)
EC2SB 10 DC4.7-9, 9-18, 18-36, 36-75 3.3, 5, 12, 15 双路
标准: 25.4 x 25.4 x 10.2
SMD: 25.4 x 25.4 x 9.2
EC2SBW 10 DC9-36, 18-75 3.3, 5, 12, 15  双路  25.4 x 25.4 x 10.2
EC7A 10 9-75 2.5, 3.3, 5, 12, 15, ±12, ±15,   ±5   DIP:31.8 x 20.3 x 10.2mm
  SMD:31.8 x 20.3 x 11.4mm
EC2SB 10 9-75 3.3, 5, 12, 15   25.4 x 25.4 x 10.2mm
  SMD:25.4 x 25.4 x 9.2mm
EC4BE 10 9-72 5, 12, 15, ±12,   ±15, ±5   50.8 x 25.4 x 10.2mm
EC4BW 10 9-72 3.3, 5, 12, 15, ±12,   ±15, ±5   50.8 x 25.4 x 10.2mm
EC8B 10.8-15 18-75 1.8, 2.5, 3.3, 5   50.8 x 25.4 x 10.2mm
EC1SB 13.2-15 18-75 3.3, 5, 12, 15   27.9 x 24.4 x 9.1 mm



EC2SC





14.4-25 9-75 1.8, 2.5, 3.3, 5.0, 12, 15   Metal Case:50.8 x 40.6 x 11.4mm
  Open Frame:49.5 x 39.4 x 10.2mm
EC8AW 15 9-36, 18-75 3.3, 5, 12, 15, ±12, ±15   31.8x20.3x10.2mm
EC3C 15 9-72 3.3, 5, 12, 15, ±12,   ±15, ±5   50.8 x 50.8 x 10.2mm
EC5C 15 9-72 3.3, 5, 12, 15, ±12,   ±15, ±5, 5/±12, 5/ ±15   50.8 x 50.8 x 10.2mm
EC3SB 15 9-75 3.3, 5, 12, 15   25.4 x 25.4 x 10.2mm
  SMD:25.4 x 25.4 x 9.2mm
EC5BE 15 9-72 3.3, 5, 12, 15, ±12,   ±15, ±5   50.8 x 25.4 x 10.2mm
EC5BW 15 9-75 3.3, 5, 12, 15, ±12,   ±15, ±5   50.8 x 25.4 x 10.2mm
EC3CB 15 9-72 3.3, 5, 12, 15, ±12,   ±15, ±5   50.8 x 50.8 x 10.2mm
EC2EE 15 9-72 5, 12, 15, ±12,   ±15, 5.0/±12, 5.0/ ±15, +5/+12/-5   65.0 x 76.2 x 21.1 mm

EC4EE 15 9-72 5, 12, 15, ±12,   ±15, 5.0/±12, 5.0/ ±15, +5/+12/-5   65.0 x 76.2 x 21.1 mm

EC3SBW 15 9-75 3.3, 5, 12, 15, ±12,   ±15, ±5   DIP:25.4 x 25.4 x 10.2mm
  SMD:25.4 x 25.4 x 11.94mm
EC7BW 20 9-75 3.3, 5, 12, 15   50.8 x 25.4 x 10.2mm
EC7B 20 9-75 1.8, 2.5, 3.3, 5, 12, 15, ±12,   ±15, ±5   50.8 x 25.4 x 10.2mm
EC1SC 20 9-72 3.3, 5, 12, 15, ±12,   ±15, ±5   50.8 x 46.6 x 11.4mm
EC3SCW 20-30 9-75 3.3, 5, 12, 15   Metal Case:50.8 x 40.6 x 10.2mm
EC9BW 30 9-75 3.3, 5, 12, 15, ±12,   ±15   50.8 x 25.4 x 10.2mm
EC5E 20-30 9-72 5, 12, 15, ±12,   ±15, 5.0/±12, 5.0/ ±15, +5/+12/-5   65.0 x 76.2 x 21.1 mm
EC6E 20-30 9-72 5, 12, 15, ±12, ±15, 5.0/±12, 5.0/ ±15, +5/+12/-5   65.0 x 76.2 x 21.1 mm
ECLB40W 40 9-36, 18-75 3.3, 5, 12, 15, ±12,   ±15   52.0x30.5x10.2mm
ECLB40W
-110
40 43-160 3.3, 5, 12, 15, ±12,   ±15   52.0x30.5x10.2mm
